61
3.3.9 Onboard Devices Configuration
Onboard Lan1/Lan2 (82576)
Enable /disable Lan controller.
Enabled / Disabled
Onboard Lan1/Lan2 OP-ROM
Execute Lan OP-ROM or not.
Disabled / Enabled
Onboard Lan3 (82574)
Enable /disable Lan controller.
Enabled / Disabled
Onboard Lan3 OP-ROM
Execute Lan OP-ROM or not.
Disabled / Enabled
Onboard SAS (optional)
Enable or disable the onboard SAS controller.
Enabled / Disabled
Onboard VGA
Enable or disable the onboard VGA controller.
Enabled / Disabled
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security Chipset Exit
Onboard Device and PCI Slots Configuration
Onboard LAN 1/2 (82576)
Onboard LAN 1 OP ROM
Onboard LAN 2 OP ROM
Onboard LAN 3 (82574)
Onboard LAN 3 OP ROM
Onboard SAS
Onboard VGA
[Enabled]
[Disabled]
[Disabled]
[Enabled]
[Disabled]
[Enabled]
[Enabled]
Enabled
Disabled
←
Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
