14
LED Definitions
Pin Signal
+ +3V
- SAS_FLASH_RY
State Description
OFF OFF
(SAS SKU Only) The SAS
firmware is not updated.
LED2
SAS Flash
Ready
Blinking Amber
(SAS SKU Only) The LED shows
blinking amber when the system is
updating the SAS firmware.
Pin Signal
+ +3V
- LED_SASHDD_FAULT-
State Description
OFF OFF
(SAS SKU Only) The LED shuts
off when the RAID is functioning
normally.
LED3
SAS HD
Fault LED
ON Amber
(SAS SKU Only) The amber LED
lights up when the SAS controller
detects errors in RAID.
Pin Signal
+ +3V
- GND
State Description
OFF OFF Power Off
LED4
Power On
LED
ON Green Power On
Pin Signal
+ +3VSB
- GND
State Description
OFF OFF
The power supply is not plugged in
or the power supply unit can not
work properly.
LED5
Standby
LED
ON Green
The green Standby LED is lit up
when the system is in idle mode.
Pin Signal
+ +3V
- GND
State Description
OFF OFF
The LED shuts off when the
onboard SAS controller can not
work properly.
LED6
SAS Error
LED
ON Amber
(SAS SKU Only) When the
onboard SAS controller detects
errors, the LED will turn amber.
