Location of Controls and Functions Operator's Manual LDK 23HS mkII - HS Camera System 4-1
This section shows the physical location of the controls and connectors on the camera. These are
grouped according to their function so as to provide a quick reference guide to the operation of a
particular aspect of the camera.
Section 4
Location of Controls and Functions
Power Supply ..................................................... 4-2
Video Functions ................................................. 4-3
Monitoring Functions .......................................... 4-5
Viewfinder .......................................................... 4-7
Viewfinder Indicators .......................................... 4-8
Contents
Control Functions ............................................... 4-9
Audio / Intercom .............................................. 4-10
Auxiliary Functions .......................................... 4-12
CPU output Functions ...................................... 4-13
