FRU Description TI Part No. Reference
Paragraph
No.
Cable Assembly, Inverter (12P) 9811386-0001 6.5.8
LCD Cover, DSSTN, 10.4 inch 9811372 6.5.8
6.4.2 System Base Assembly
As shown in Figure 6-2, the System Base Assembly houses a variety of
field-replaceable subassemblies and components. The FRUs and paragraph
references for removal/replacement procedures are listed in Table 6-2.
Table 6-3 contains a listing of Customer (non-technical user) replaceable
units (CRUs) and associated TI Part Numbers.
Table 6-2 Base Assembly, Field-Replaceable Units (FRUs)
FRU Description TI Part No. Reference
Paragraph
No.
Main Board without CPU (transfer CPU to
replacement board) 9811726-0001 6.5.13
IC, CPU, P54LM-100 SPGA (2.9V) 9811733-0001 6.5.14
Button Board Assembly 9811367-0001 6.5.6
Touchpad Board Assembly 9803991-0001 6.5.4
Smart Battery Control Board Assembly 9811734-0001 6.5.4
LED/Switch PWB Assembly 9811358-0001 6.5.4
Charger/Power Supply Board Assembly 9811360-0001 6.5.4
Floppy Drive Assembly 9811394-0001 6.5.5
Hard Disk Drive, 810 Million Byte 9811396-0001 6.5.6
Keyboard Assembly, U.S., EXT50x/51x 9811398-0001 6.5.2
Keyboard Assembly, UK, EXT50x/51x 9811398-0002 6.5.2
Keyboard Assembly, GER, EXT50x/51x 9811398-0003 6.5.2
Keyboard Assembly, FRA, EXT50x/51x 9811398-0004 6.5.2
Keyboard Assembly, SPN, EXT50x/51x 9811398-0005 6.5.2
Keyboard Assembly, SWS, EXT50x/51x 9811398-0006 6.5.2
Keyboard Assembly, ITA, EXT50x/51x 9811398-0007 6.5.2
Keyboard Assembly, PORT, EXT50x/51x 9811398-0009 6.5.2
Field Service 6-5
