Start-up Checklist
and Log
Installing Contractor:
Use this form to thoroughly check-out the system and units before and during
start-up. (This form need not be returned to the factory unless requested during technical service support).
Job Name:
Model Number:
Date:
Serial Number:
In order to minimize troubleshooting and costly system failures, complete the following checks and data
entries before the system is put into full operation.
MODE
Entering fluid temperature
Leaving fluid temperature
Temperature differential
Return-air temperature DB/WB
Supply-air temperature DB/WB
Temperature differential
Water coil heat exchanger
(Water Pressure IN)
Water coil heat exchanger
(Water Pressure OUT)
Pressure Differential
HEAT
F
COOL
F
F
F
F
F
PSIG
PSIG
PSIG
PSIG
PSIG
PSIG
COMPRESSOR
Amps
Volts
Discharge line temperature
(after 10 minutes)
F
F
F
F
F
F
F
F
