Trane WPVJ - Manual (Page 21)

WSHP-SVX04A-EN 21
Table E1: WPVJ Electrical Performance (Standard Static Blower Option-continued)
Table E2: WPVJ Electrical Performance (High Static Blower Option)
Model
No.
Volts/Hz/Ph Total
FLA
Comp.
RLA (ea)
Comp.
LRA (ea)
No. of
Compres.
Cmp
MCC Blower
Motor
FLA
Blower
Motor
HP
Fan Motor
Num
Minimum
Circuit
Ampacity
Overcurrent
Protective
Device
Desup Desup
RLA
WPVJ048 208/60/1 23.3 20.40 109.0 1 28.6 2.90 1/2 1 28.4 45 No 0
WPVJ048 208/60/1 23.51 20.40 109.0 1 28.6 2.90 1/2 1 28.6 45 Yes 0.21
WPVJ048 208/60/3 16.8 13.90 88.0 1 19.4 2.90 1/2 1 20.3 30 No 0
WPVJ048 208/60/3 17.01 13.90 88.0 1 19.4 2.90 1/2 1 20.5 30 Yes 0.21
WPVJ048 230/60/1 23.3 20.40 109.0 1 28.6 2.90 1/2 1 28.4 45 No 0
WPVJ048 230/60/1 23.51 20.40 109.0 1 28.6 2.90 1/2 1 28.6 45 Yes 0.21
WPVJ048 230/60/3 16.8 13.90 88.0 1 19.4 2.90 1/2 1 20.3 30 No 0
WPVJ048 230/60/3 17.01 13.90 88.0 1 19.4 2.90 1/2 1 20.5 30 Yes 0.21
WPVJ048 380-415/50/3 8.5 7.10 44.0 1 10.0 1.40 1/2 1 10.3 15 No 0
WPVJ048 460/60/3 8.5 7.10 44.0 1 10.0 1.40 1/2 1 10.3 15 No 0
WPVJ048 460/60/3 8.71 7.10 44.0 1 10.0 1.40 1/2 1 10.5 15 Yes 0.21
WPVJ060 208/60/1 32.2 28.00 169.0 1 39.0 4.20 3/4 1 39.2 60 No 0
WPVJ060 208/60/1 32.41 28.00 169.0 1 39.0 4.20 3/4 1 39.4 60 Yes 0.21
WPVJ060 208/60/3 23.5 19.30 123.0 1 27.0 4.20 3/4 1 28.3 45 No 0
WPVJ060 208/60/3 23.71 19.30 123.0 1 27.0 4.20 3/4 1 28.5 45 Yes 0.21
WPVJ060 230/60/1 32.2 28.00 169.0 1 39.0 4.20 3/4 1 39.2 60 No 0
WPVJ060 230/60/1 32.41 28.00 169.0 1 39.0 4.20 3/4 1 39.4 60 Yes 0.21
WPVJ060 230/60/3 23.5 19.30 123.0 1 27.0 4.20 3/4 1 28.3 45 No 0
WPVJ060 230/60/3 23.71 19.30 123.0 1 27.0 4.20 3/4 1 28.5 45 Yes 0.21
WPVJ060 380-415/50/3 9.6 7.50 49.5 1 10.5 2.10 3/4 1 11.5 15 No 0
WPVJ060 460/60/3 9.6 7.50 49.5 1 10.5 2.10 3/4 1 11.5 15 No 0
WPVJ060 460/60/3 9.81 7.50 49.5 1 10.5 2.10 3/4 1 11.7 15 Yes 0.21
WPVJ060 575/60/3 8.1 6.40 40.0 1 9.0 1.70 3/4 1 9.7 15 No 0
WPVJ060 575/60/3 8.31 6.40 40.0 1 9.0 1.70 3/4 1 9.9 15 Yes 0.21
WPVJ072 208/60/1 36.3 32.10 169.0 1 45.0 4.20 3/4 1 44.3 70 No 0
WPVJ072 208/60/1 36.51 32.10 169.0 1 45.0 4.20 3/4 1 44.5 70 Yes 0.21
WPVJ072 208/60/3 23.5 19.30 137.0 1 27.0 4.20 3/4 1 28.3 45 No 0
WPVJ072 208/60/3 23.71 19.30 137.0 1 27.0 4.20 3/4 1 28.5 45 Yes 0.21
WPVJ072 230/60/1 36.3 32.10 169.0 1 45.0 4.20 3/4 1 44.3 70 No 0
WPVJ072 230/60/1 36.51 32.10 169.0 1 45.0 4.20 3/4 1 44.5 70 Yes 0.21
WPVJ072 230/60/3 23.5 19.30 137.0 1 27.0 4.20 3/4 1 28.3 45 No 0
WPVJ072 230/60/3 23.71 19.30 137.0 1 27.0 4.20 3/4 1 28.5 45 Yes 0.21
WPVJ072 380-415/50/3 12.1 10.00 62.0 1 14.0 2.10 3/4 1 14.6 25 No 0
WPVJ072 460/60/3 12.1 10.00 62.0 1 14.0 2.10 3/4 1 14.6 25 No 0
WPVJ072 460/60/3 12.31 10.00 62.0 1 14.0 2.10 3/4 1 14.8 25 Yes 0.21
WPVJ072 575/60/3 9.6 7.90 50.0 1 11.0 1.70 3/4 1 11.6 15 No 0
WPVJ072 575/60/3 9.81 7.90 50.0 1 11.0 1.70 3/4 1 11.8 15 Yes 0.21
Model No. Volts/Hz/Ph
Total
FLA
Comp.
RLA (ea)
Comp.
LRA (ea)
No. of
Compres.
Cmp
MCC
Blower
Motor
FLA
Blower
Motor
HP
Fan Motor
Num
Minimum
Circuit
Ampacity
Overcurrent
Protective
Device
Desup Desup
RLA
WPVJ018 208/60/1 10.5 9.30 47.0 1 13.0 1.20 1/5 1 12.8 20 No 0
WPVJ018 208/60/1 10.71 9.30 47.0 1 13.0 1.20 1/5 1 13.0 20 Yes 0.21
WPVJ018 220-240/50/1 9.6 8.60 39.0 1 12.0 1.00 1/5 1 11.8 20 No 0
WPVJ018 230/60/1 10.5 9.30 47.0 1 13.0 1.20 1/5 1 12.8 20 No 0
WPVJ018 230/60/1 10.71 9.30 47.0 1 13.0 1.20 1/5 1 13.0 20 Yes 0.21
WPVJ018 265/60/1 9.6 8.60 39.0 1 12.0 1.00 1/5 1 11.8 20 No 0
WPVJ018 265/60/1 9.81 8.60 39.0 1 12.0 1.00 1/5 1 12.0 20 Yes 0.21
Electrical
Requirements
