Table E3: WPHF Electrical Performance (Standard Static Blower Option-continued)
Table E4: WPHF Electrical Performance (High Static Blower Option)
Model No.
Volts/Hz/Ph
Blower Motor
HP
Blower Motor
FLA
Compr.
RLA
Compr.
MCC
Compr.
LRA
Minimum Cir-
cuit Amps
UL Max Fuse
or HACR
CSA
Max. Fuse
Size
CASE
Max.
Circuit Brkr
WPHF057
208/60/1
1/2
4.1
22.3
34.8
122
32.0
50
60
50
WPHF057
230/60/1
1/2
4.1
22.3
34.8
122
32.0
50
60
50
WPHF057
208/60/3
1/2
4.1
14.4
25.5
101
22.1
35
50
45
WPHF057
230/60/3
1/2
4.1
14.4
25.5
101
22.1
35
50
45
WPHF057
460/60/3
1/2
1.8
7.1
11.1
51
10.7
15
20
20
Model No.
Volts/Hz/Ph
Blower Motor
HP
Blower Motor
FLA
Compr.
RLA
Compr.
MCC
Compr.
LRA
Minimum Cir-
cuit Amps
UL Max Fuse
or HACR
CSA
Max. Fuse
Size
CASE
Max.
Circuit Brkr
WPHF047
208/60/1
1/2
4.6
14.6
22.8
92
22.9
35
50
40
WPHF047
230/60/1
1/2
4.6
14.6
22.8
92
22.9
35
50
40
WPHF047
208/60/3
1/2
4.6
10.6
16.5
101
17.9
25
50
45
WPHF047
230/60/3
1/2
4.6
10.6
16.5
101
17.9
25
50
45
WPHF047
460/60/3
1/2
2.2
4.2
6.6
51
7.5
15
25
20
WPHF057
208/60/1
1/2
4.6
22.3
34.8
122
32.5
50
60
50
WPHF057
230/60/1
1/2
4.6
22.3
34.8
122
32.5
50
60
50
WPHF057
208/60/3
1/2
4.6
14.4
22.5
101
22.6
35
50
45
WPHF057
230/60/3
1/2
4.6
14.4
22.5
101
22.6
35
50
45
WPHF057
460/60/3
1/2
2.2
7.1
11.1
51
11.1
15
25
20
