Table E1: WPVJ Electrical Performance (Standard Static Blower Option)
Model
No.
Volts/Hz/Ph Total
FLA
Comp.
RLA (ea)
Comp.
LRA (ea)
No. of
Compres.
Cmp
MCC Blower
Motor
FLA
Blower
Motor
HP
Fan Motor
Num
Minimum
Circuit
Ampacity
Overcurrent
Protective
Device
Desup Desup
RLA
WPVJ018 208/60/1 10.1 9.30 47.0 1 13.0 0.80 1/8 1 12.4 20 No 0
WPVJ018 208/60/1 10.31 9.30 47.0 1 13.0 0.80 1/8 1 12.6 20 Yes 0.21
WPVJ018 220-240/50/1 9.81 8.60 39.0 1 12.0 1.00 1/5 1 12.0 20 No 0.21
WPVJ018 230/60/1 10.1 9.30 47.0 1 13.0 0.80 1/8 1 12.4 20 No 0
WPVJ018 230/60/1 10.31 9.30 47.0 1 13.0 0.80 1/8 1 12.6 20 Yes 0.21
WPVJ018 265/60/1 9.6 8.60 39.0 1 12.0 1.00 1/5 1 11.8 20 No 0
WPVJ018 265/60/1 9.81 8.60 39.0 1 12.0 1.00 1/5 1 12.0 20 Yes 0.21
WPVJ024 208/60/1 12.6 11.40 56.0 1 16.0 1.20 1/5 1 15.5 25 No 0
WPVJ024 208/60/1 12.81 11.40 56.0 1 16.0 1.20 1/5 1 15.7 25 Yes 0.21
WPVJ024 220-240/50/1 10.6 9.60 47.0 1 13.5 1.00 1/5 1 13.0 20 No 0
WPVJ024 230/60/1 12.6 11.40 56.0 1 16.0 1.20 1/5 1 15.5 25 No 0
WPVJ024 230/60/1 12.81 11.40 56.0 1 16.0 1.20 1/5 1 15.7 25 Yes 0.21
WPVJ024 265/60/1 10.81 9.60 47.0 1 13.5 1.00 1/5 1 13.2 20 Yes 0.21
WPVJ024 265/60/1 10.6 9.60 47.0 1 13.5 1.00 1/5 1 13.0 20 No 0
WPVJ030 208/60/1 15.1 13.60 67.0 1 19.0 1.50 1/4 1 18.5 30 No 0
WPVJ030 208/60/1 15.31 13.60 67.0 1 19.0 1.50 1/4 1 18.7 30 Yes 0.21
WPVJ030 220-240/50/1 13.4 12.10 58.0 1 17.0 1.30 1/4 1 16.4 25 No 0
WPVJ030 230/60/1 15.1 13.60 67.0 1 19.0 1.50 1/4 1 18.5 30 No 0
WPVJ030 230/60/1 15.31 13.60 67.0 1 19.0 1.50 1/4 1 18.7 30 Yes 0.21
WPVJ030 265/60/1 13.4 12.10 58.0 1 17.0 1.30 1/4 1 16.4 25 No 0
WPVJ030 265/60/1 13.61 12.10 58.0 1 17.0 1.30 1/4 1 16.6 25 Yes 0.21
WPVJ036 208/60/1 17.8 15.00 73.0 1 21.0 2.80 1/3 1 21.6 35 No 0
WPVJ036 208/60/1 18.01 15.00 73.0 1 21.0 2.80 1/3 1 21.8 35 Yes 0.21
WPVJ036 208/60/3 13.5 10.70 63.0 1 15.0 2.80 1/3 1 16.2 25 No 0
WPVJ036 208/60/3 13.71 10.70 63.0 1 15.0 2.80 1/3 1 16.4 25 Yes 0.21
WPVJ036 220-240/50/1 16.6 14.30 71.0 1 20.0 2.30 1/3 1 20.2 30 No 0
WPVJ036 230/60/1 17.8 15.00 73.0 1 21.0 2.80 1/3 1 21.6 35 No 0
WPVJ036 230/60/1 18.01 15.00 73.0 1 21.0 2.80 1/3 1 21.8 35 Yes 0.21
WPVJ036 230/60/3 13.5 10.70 63.0 1 15.0 2.80 1/3 1 16.2 25 No 0
WPVJ036 230/60/3 13.71 10.70 63.0 1 15.0 2.80 1/3 1 16.4 25 Yes 0.21
WPVJ036 265/60/1 16.6 14.30 71.0 1 20.0 2.30 1/3 1 20.2 30 No 0
WPVJ036 265/60/1 16.81 14.30 71.0 1 20.0 2.30 1/3 1 20.4 30 Yes 0.21
WPVJ036 380-415/50/3 6.1 5.00 31.0 1 7.0 1.10 1/3 1 7.4 15 No 0
WPVJ036 460/60/3 6.1 5.00 31.0 1 7.0 1.10 1/3 1 7.4 15 No 0
WPVJ036 460/60/3 6.31 5.00 31.0 1 7.0 1.10 1/3 1 7.6 15 Yes 0.21
WPVJ042 208/60/1 21.3 18.40 95.0 1 25.8 2.90 1/2 1 25.9 40 No 0
WPVJ042 208/60/1 21.51 18.40 95.0 1 25.8 2.90 1/2 1 26.1 40 Yes 0.21
WPVJ042 208/60/3 14.3 11.40 77.0 1 16.0 2.90 1/2 1 17.2 25 No 0
WPVJ042 208/60/3 14.51 11.40 77.0 1 16.0 2.90 1/2 1 17.4 25 Yes 0.21
WPVJ042 230/60/1 21.3 18.40 95.0 1 25.8 2.90 1/2 1 25.9 40 No 0
WPVJ042 230/60/1 21.51 18.40 95.0 1 25.8 2.90 1/2 1 26.1 40 Yes 0.21
WPVJ042 230/60/3 14.3 11.40 77.0 1 16.0 2.90 1/2 1 17.2 25 No 0
WPVJ042 230/60/3 14.51 11.40 77.0 1 16.0 2.90 1/2 1 17.4 25 Yes 0.21
WPVJ042 380-415/50/3 7.1 5.70 39.0 1 8.0 1.40 1/2 1 8.5 15 No 0
WPVJ042 460/60/3 7.1 5.70 39.0 1 8.0 1.40 1/2 1 8.5 15 No 0
WPVJ042 460/60/3 7.31 5.70 39.0 1 8.0 1.40 1/2 1 8.7 15 Yes 0.21
Electrical
Requirements
