Electrical Characteristics (continued): iFA48021A280V- 000 through - 003: 28V, 21.4A Output
Start-up Characteristics with maximum capacitive load (C=7,000uF)
from input voltage application at full load.
Ch.1: Vout, Ch.3: Vin, Ch.4: Load Current Typical Dynamic Load Response. Load step from 50% to 75% of
full load, di/dt= 0.1A/uS. (Note: Vin=48V)
Ch.1: Output Voltage, Ch. 4: Load Current
Output Voltage vs. Input Voltage (Line Regulation) at Ta=25 °C. Typical Input Start-up Current vs. Load Current at Ta=25 °C
Typical Output Voltage vs. Input Voltage During Start-up, Ta=25 °C Typical Current Limit vs. Input Voltage at Ta=25 °C
