TPA005D02 Audio Power Amplifier Evaluation Module Parts List
3-29
Details
3.5
TPA005D02 Audio Power Amplifier Evaluation Module Parts List
Table 3–3. TPA005D02 Class D EVM Parts List
Reference
Description
Size
EVM
Qty.
Manufacturer/
Part Number
C1, C2, C3, C6
C7, C9, C12, C13,
C16, C17, C18, C19
Capacitor, Ceramic, 1
µ
F,
16 V, Y5V, +80% –20%
0805
12
muRata
GRM40Y5V105Z16
C4, C5, C8
Capacitor, Ceramic, 470 pF,
50 V, X7R, 10%
0603
3
muRata
GRM39X7R471K50
C20, C21
Capacitor, Ceramic, 0.047
µ
F,
50 V, X7R, 10%
0805
2
muRata
GRM40X7R473K50
C10, C11
Capacitor, Ceramic, 10
µ
F,
16 V, Y5V, +80%–20%
1210
2
muRata
GRM235Y5V106Z16
C14, C15
Capacitor,Tantalum, 220
µ
F,
10 V, 20%
Case E
2
AVX
TPSE227M010
C24, C25, C26, C27
Capacitor, Ceramic, 0.22
µ
F,
25 V, X7R, 10%
0603
4
muRata
GRM39X7R224K10
C22, C23
Capacitor, Metal Film, 1
µ
F,
50 V,
±
5%, leaded
0.287
Ч
0.315
Ч
0.197
2
Panasonic
ECQ-V1H105JI
D2, D3
LED, SM, Green, 25 mcd,
2.1 V, 120 deg
0.134
Ч
0.11
Ч
0.071
2
Lumex
SML-LX2832GC-TR
L1, L2, L3, L4
Inductor, 15
µ
H, 3.1 A rms,
0.060
Ω
0.51
Ч
0.37
Ч
0.30
4
Coilcraft
DO3316P-153
Q1
Transistor, PNP, 60 V, 200 mA
SOT-23
1
Zetex
FMMT3906CT-ND
R1, R3
Resistor, SMD, MF, 20 k
Ω
,
1/16 W, 5%
0603
2
Vishay/Dale
CRCW0603203J
R2, R6, R7
Resistor, SMD, MF, 1 k
Ω
,
1/16 W, 5%
0603
3
Vishay/Dale
CRCW0603102J
R4, R5
Resistor, SMD, MF, 100 k
Ω
, 1/16
W, 5%
0603
2
Vishay/Dale
CRCW0603104J
S1, S2
Switch, Momentary, PB, 12 VDC,
50 mA
0.291
Ч
0.138
Ч
0.134
2
Panasonic
EVQ-PJS04K
U1
IC, Audio amplifier, class D,
5 W, 48 pin, DCA pkg
TSSOP48
1
TI
TPA005D02DCA
D1
Diode, Zener, SMT, 3.9 V,
500 mW, 50
µ
A, 1N4686
SOD-123
1
Motorola
MMSZ4686T1
