2-1 Quick Start
Quick Start
Follow the steps in this chapter to quickly prepare the TPA005D02 Class D
Stereo Audio Amplifier EVM for use. Using the TPA005D02 class D EVM with
the TI Plug-N-Play Audio Amplifier Evaluation Platform is a quick and easy way
to connect power, signal and control inputs, and signal outputs to the EVM
using standard connectors. However, the audio amplifier evaluation module
can be used stand-alone by making connections directly to the module pins,
and it can be wired directly into existing circuits or equipment.
The platform switch and jumper settings shown in Table 2–1 are typical for the
TPA005D02 class D EVM.
Table 2–1. Typical TI Plug-N-Play Platform Jumper and Switch Settings for the
TPA005D02 Class D EVM
EVM JP6 JP7 JP8 S2 S3
P-N-P Platform Mute X Lo Note 2 U5
Notes: 1) X = Don’t care
2) Set S2 to ON when signal conditioning board is installed in U1; set S2
to OFF when no signal conditioning board is installed.
Topic Page
2.1 Precautions 2–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Quick Start List for Platform 2–3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Quick Start List for Stand-Alone 2–5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2
