User’s Manual 4-57
Operating Basics
O
PER
ATING
B
ASICS
2. Plug one end of the cable into the LAN jack. Press gently until you hear the
latch click into place.
Figure 4-21 Connecting the LAN cable
3. Plug the other end of the cable into a LAN hub connector. Check with your
LAN administrator before connecting to a hub.
Disconnecting LAN cable
To disconnect the LAN cable, follow the steps below.
1. Pinch the lever on the connector in the computer’s LAN jack and pull out
the connector.
2. Disconnect the cable from the LAN hub in the same manner. Check with
your LAN administrator before disconnecting from the hub.
When the computer is exchanging data with the LAN, the LAN
active
indicator glows amber. When the computer is connected to
a LAN hub but is not exchanging data, the Link indicator glows
green.
Make sure the LAN active indicator (amber LED) is out before
you disconnect the computer from the LAN.
LAN J ACK
