Appendix B Specifications
Trango Broadband Wireless — TrangoLINK-45 page 54
Antennas
Integrated 19 dBi Antenna (for P5055M-19-xx)
Frequency range:
4950-5850 MHz
Gain: 19 dBi +/- 1 dB
Front/Back Ratio >30 dB
E-Plane Beamwidth: > 18 degrees typical
H-Plane Beamwidth: > 18 degrees typical
Polarization: Vertical and Horizontal
Port/Port Isolation: 20 dB typ
Cross Pol Rejection: 20 dB typ
VSWR: <1.7:1
Package: Alumininum backplate with plastic radome.
Dimensions: 8.5" x 7.75" x 1.25" (216mm x 197mm x 32mm)
Weight: 2 lbs (.91Kg)
Mounting Provisions: Mounting kit supplied for up to 3”diam pole or flat surface
Azimuth/El Adjust: +/-30 degrees
Sealing: Water tight to 1 meter IEC 529/IP67
Temp Range: -40 deg F to +160 deg F (-40 deg C to +60 deg C)
Wind speed operational: 100 mph (160 km/hr)
Wind speed survival :
140 mph (220 km/hr)
Integrated 23 dBi Antenna (for P5055M-23-xx)
Frequency range:
4950-5850 MHz
Gain: 23 dBi +/- 1 dB
Front/Back Ratio >35 dB
E-Plane Beamwidth: > 9 degrees typical
H-Plane Beamwidth: > 9 degrees typical
Polarization: Vertical and Horizontal
Port/Port Isolation: 40 dB typ
Cross Pol Rejection: 25 dB typ
VSWR: <1.7:1
Package: Alumininum backplate with plastic radome.
Dimensions: 14.6”x 14.6”x 1.58” (371mm x 371mm x 40mm)
Weight: 5.5 lbs (2.5 kg)
Mounting Provisions: Mounting kit supplied for up to 3”diam pole or flat surface
Azimuth/El Adjust: +/-30 degrees
Sealing: Water tight to 1 meter IEC 529/IP67
Temp Range: -40 deg F to +160 deg F (-40 deg C to +60 deg C)
Wind speed operational: 100 mph (160 km/hr)
Wind speed survival :
140 mph (220 km/hr)
FCC Certified External Antennas (for P5055M-EXT-xx)
Radiowaves models:
SPD4-5.2, SPD3-5.2, SPD2-5.2, SPD1-5.2
See Radiowaves, Inc. for specifications and details
