Overview Range vs. Throughput
Trango Broadband Wireless — TrangoLINK-45 page 10
Range vs. Throughput
The following table shows approximate maximum ranges (at recommended fade margins) achievable with the
TrangoLINK-45 system using various antenna configurations. Longer ranges are achievable, but will result in lower fade
margins. To estimate theoretical throughput and fade margin for any distance, download the link budget / fade margin
calculator tool from www.trangobroadband.com .
ISM (5725 MHz to 5875 MHz) Line-of-Sight Range & Throughput
Antenna 5 miles 20 miles 30 miles
Integrated 23 dBi
15” Flat Panel
45 Mbps
(10 db fade margin)
11 Mbps
(14 db fade margin)
6 Mbps
(17 db fade margin)
External 27 dBi
2’ Dish
45 Mbps
(18 db fade margin)
20 Mbps
(18 db fade margin)
10 Mbps
(20 db fade margin)
External 30 dBi
3’ Dish
45 Mbps
(24 db fade margin)
26 Mbps
(20 db fade margin)
18 Mbps
(22 db fade margin)
External 34 dBi
4’ Dish
45 Mbps
(30 db fade margin)
32 Mbps
(20 db fade margin)
30 Mbps
(15 db fade margin)
U-NII (5470 MHz to 5725 MHz & 5250 MHz to 5350 MHz) Line-of-Sight Range & Throughput
Antenna 6 miles 10 miles 15 miles
Integrated 23 dBi
15” Flat Panel
20 Mbps
(10 db fade margin)
11Mbps
(12 db fade margin)
6Mbps
(9 db fade margin)
External 27 dBi
2’ Dish
31 Mbps
(11 db fade margin)
20 Mbps
(10 db fade margin)
11Mbps
(12 db fade margin)
External 30 dBi
3’ Dish
31 Mbps
(14 db fade margin)
20 Mbps
(13 db fade margin)
16Mbps
(12 db fade margin)
External 34 dBi
4’ Dish
45 Mbps
(10 db fade margin)
30 Mbps
(13 db fade margin)
20Mbps
(14 db fade margin)
