Appendix B
Specifications
Trango Broadband Wireless — TrangoLINK-45
page 49
Appendix B Specifications
RF Parameters
RF Conducted Power and Receiver sensitivity for 1x10
-3
Frame error rate with ARQ active:
- US / IC MODELS*
Speed
Setting
(over-the-air
rate) (Mbps)
Modulation
Scheme
Receiver
Sensitivity
(dB)
Max Power
5.18 to 5.24 GHz
(dBm)
Max Power
5.265- 5.325, 5.5 to 5.7 GHz
(DFS-UNII) (dBm)
Max Power
5.735 to 5.84
GHz (ISM)
(dBm)
6(5) BPSK -92
NA
+2 (-EXT) ,+6 (-23), +10(-19)
+21
12(11) QPSK
-87
NA
+2 (-EXT) ,+6 (-23), +10(-19)
+19
18(16) QPSK
-85
NA
+2 (-EXT) ,+6 (-23), +10(-19)
+19
24(20) 16QAM
-84
NA
+2 (-EXT) ,+6 (-23), +10(-19)
+18
36(31) 16QAM
-80
NA
+2 (-EXT) ,+6 (-23), +10(-19)
+18
48(40) 64QAM
-75
NA
+2 (-EXT) ,+6 (-23), +10(-19)
+17
54(45) 64QAM
-73
NA
+2 (-EXT) ,+6 (-23), +10(-19)
+17
*Note IC models excludes 5.600-5.650GHz frequency range.
- EU MODELS
Speed
Setting
(over-the-air
rate) (Mbps)
Modulation
Scheme
Receiver
Sensitivity
(dB)
Max Power
5.18 to 5.24 GHz
(ETSI) (dBm)
Max Power
5.26- 5.32, 5.5 to 5.7 GHz
(ETSI) (dBm)
Max Power
5.725 to
5.85 GHz
(dBm)
6(5) BPSK
-92
NA (-EXT) ,+0 (-23), +4(-19)
+3 (-EXT) ,+7 (-23), +11(-19)
NA
12(11) QPSK -87
NA (-EXT) ,+0 (-23), +4(-19)
+3 (-EXT) ,+7 (-23), +11(-19)
NA
18(16) QPSK -85
NA (-EXT) ,+0 (-23), +4(-19)
+3 (-EXT) ,+7 (-23), +11(-19)
NA
24(20) 16QAM -84
NA (-EXT) ,+0 (-23), +4(-19)
+3 (-EXT) ,+7 (-23), +11(-19)
NA
36(31) 16QAM -80
NA (-EXT) ,+0 (-23), +4(-19)
+3 (-EXT) ,+7 (-23), +11(-19)
NA
48(40) 64QAM -75
NA (-EXT) ,+0 (-23), +4(-19)
+3 (-EXT) ,+7 (-23), +11(-19)
NA
54(45) 64QAM -73
NA (-EXT) ,+0 (-23), +4(-19)
+3 (-EXT) ,+7 (-23), +11(-19)
NA
- OE MODELS
Speed
Setting
(Max Tput)
(Mbps)
Modulation
Scheme
Receiver
Sensitivity
(dB)
Max Power
5.18 to 5.24 GHz
(ETSI) (dBm)
Max Power
5.26- 5.32, 5.5 to 5.7 GHz
(ETSI) (dBm)
Max Power
5.725 to
5.85 GHz
(dBm)
6(5) BPSK
-92
+14
+14
+21
12(11) QPSK -87
+13 +13
+19
18(16) QPSK -85
+13 +13
+19
24(20) 16QAM -84
+12 +12
+18
36(31) 16QAM -80
+12 +12
+18
48(40) 64QAM -75
+11 +11
+17
54(45) 64QAM -73
+11 +11
+17
NOTE: Numbers in parentheses are actual max user aggregate throughput speeds
