Getting Started System Information (sysinfo) Page
Trango Broadband Wireless — TrangoLINK-45 page 19
[Remarks] User entered remarks up to 256 characters. Field accepts alpha numeric’s
only. Special characters (!@#$%^&*()\?/) require quotations.
Section 6
[Eth Config]
Configuration setting of Ethernet port which will also be ANEG
[Eth Status] The current status of Ethernet port 100FDX/100HDX/10FDX/10HDX
[Eth In] Counter for Ethernet packets which entered via the Ethernet port
[Eth Tx] Counter for Ethernet packets which exited via the Ethernet port
[RF Rx] Counter for Ethernet packets which entered via the wireless link
[RF Tx] Counter for Ethernet packets which exited via the wireless link
[ARQ Retransmissions] Counter for the number of packets retransmitted via ARQ.
