Getting Started
System Information (sysinfo) Page
Trango Broadband Wireless — TrangoLINK-45
page 18
[S/N]
Serial Number of Radio
[IP]
User
defined
IP
Address
of
radio
[Subnet Mask]
User entered IP Subnet Mask
[Gateway]
User entered IP address of the default router or gateway on the local
Ethernet segment
Section 2
[PoE
Voltage]
The
voltage
the ODU received from the Jbox.
[Radio Temp]
The internal radio temperature in Celsius
[Opmode]
Operation mode of the radio: ON = transmitting, OFF= not transmitting
[Default Opmode]
Opmode which the radio defaults to after reboot.
[Active Channel]
Active RF Channel and Antenna polarization
[Freq]
Frequency
of
active
channel
[Speed]
Modulation
Speed
(6,12,18,24,36,
54
Mbps)
[Tx
Power]
Transmit
Power
[Power Range]
Allowable power range for chosen Frequency (dBm)
[Peer ID]
MAC Address of remote radio
[Status]
Connection status of remote radio (connected or disconnected)
[RSSI]
Measured signal strength from remote radio (dBm)
[Peer IP Config]
Remote radio’s IP subnet, and default Gateway configuration
[DFS
Status]
The
current
status
of
DFS.
Section 3
Channel Table: (MHz, n/a: not available in current area)
[Ch#01] 5265 dfs [Ch#02] 5285 dfs [Ch#03] 5305 dfs [Ch#04] 5325 dfs
[Ch#05] 5500 dfs [Ch#06] 5520 dfs [Ch#07] 5540 dfs [Ch#08] 5560 dfs
[Ch#09] 5580 dfs [Ch#10] 5600 dfs [Ch#11] 5620 dfs [Ch#12] 5640 dfs
[Ch#13] 5660 dfs [Ch#14] 5680 dfs [Ch#15] 5700 dfs [Ch#16] 5735
[Ch#17] 5755 [Ch#18] 5775 [Ch#19] 5795 [Ch#20] 5815
[Ch#21] 5835 [Ch#22] 5840
[Ch#23] 5840 [Ch#24] 5840
Section 4
[Area Code]
Region (country code). Defines allowable frequencies. Area code is set by
the manufacturer and can not be altered by the user.
RF Band #1 (5180..5240 MHz)
Disabled
RF Band #2 (5260..5325 MHz)
[Power Range] -4..7/7/7/7 dBm
RF Band #3 (5480..5720 MHz)
Disabled
RF Band #4 (5735..5835 MHz)
[Power Range] -4..21/19/18/17 dBm
Section 5
[Tx MIR]
Maximum Information Rate (Mbps). User may set Tx MIR in MU and RU
to different values.
[ARQ]
Automatic Retransmit Request (On or Off)
[Encrypt]
Encryption
(On
or
Off)
[Key]
Hexadecimal Encryption Key (must match in MU and RU)
[Auto Rate Shift]
Automatic Rate Shift (adaptive modulation) (On or Off)
[Auto Scan MU]
Auto Scan MU (RU setting only) (On or Off)
[RSSI LED]
Enable or disable RSSI LEDs on bottom of radio. Disabling RSSI LEDs
improves system performance.
