Output digital:
SP/DIF output
electrical, cinch socket
optical, Toslink
Dolby Digital AC3
Video parameters:
Output:
Output level FBAS
1 Vs-s +/- 0.3 dB into 75 Ohms
Output level Y 1 Vs-s +/- 0.3 dB into 75 Ohms
Output level C 1 Vs-s +/- 0.3 dB into 75 Ohm
Output level RED 0,7 Vs-s +/- 0.1Vp-p into 75 Ohms
Output level GREEN 0,7 Vs-s +/- 0.1Vp-p into 75 Ohms
Output level BLUE 0,7 Vs-s +/- 0.1Vp-p into 75 Ohms
S/N loaded > 60 dB
Teletext
Teletext filtering
corresponding to ETS 300 472
Standard
Download Teletext data (FBAS) corresponding to ITU-R
BT.653-2 lines: 6-22 and 320-335
Soft teletext 800 pages memory
TV SCART:
Output:
FBAS or RGB
VCR SCART:
Input: FBAS
Output: FBAS
Video Cinch:
Output
FBAS
S-VHS Hosiden socket:
Output
Y signal (luminance),
C signal (chrominance)
Hard drive:
Hard drive type
3,5 inch
Capacity 40 GB (Standard)
Hard drive control provided for 20 to 120 GB
No. of recordings 1000 (max.)
Display:
Vacuum fluorescence
16 digit, 5x7 point matrix, 7 mm
symbol height
Serial interface RS 232:
Type
RS 232, bidirectional
Bit rate 115,2 kBit/s max.
Connection D-SUB socket, 9 pin
Function Update for operating software and
pre-programming
LNC power supply:
LNC power
400 mA max.; double insula
ted
LNC voltage vertical <14,0V no load, > 11,5 V at 400
mA
LNC voltage horizontal < 20 V no load, > 17,2 V at 400
mA
