Texas Instruments MSP-FET430 User Manual
Page 77
D-1
Appendix D
80-pin MSP430F44x and MSP430F43x
Device Emulation
80-pin MSP430F44x and MSP430F43x devices can be emulated by the
100-pin MSP430F449 device.
Table D-1. F4xx/80-pin Signal Mapping lists where the pin signals of an 80-
pin device appear on the pins of an MSP-TS430PZ100 Target Socket
module. Note: The MSP-TS430PZ100 must be modified as indicated.
Refer to Appendix C.1.6 EMULATOR->ADVANCED->EMULATION MODE
to enable the emulation mode.
