28
Items to be checked Symptom
No picture 䡗 Is power supplied correctly?
䡗 Is the lens iris adjusted correctly?
䡗 Are the camera and video cables connected correctly?
䡗 Is the shutter mode set correctly?
䡗 Is the cable connector loose?
䡗 Are the other cables connected correctly?
䡗 Does the video output from the camera match with the input signals from
the monitor?
Unstable picture
Noise problem
Poor color
䡗 Is the monitor adjusted correctly?
䡗 Is the white balance of the camera adjusted correctly?
(in modes other than automatic tracking)
䡗
Is the matrix color correction set correctly?
䡗 Is the illumination sufficient?
8. BEFORE MAKING SERVICE CALL
Power supply 12V DC㼳10%
Power consumption Approx. 4.1 W
Image sensor 1/3 inch color CMOS sensor (Rolling shutter)
Output pixels Horizontal : 1920, Vertical : 1080
Signal system 1080/59.94p, 1080/50p, 1080/59.94i, 1080/50i, 720/59.94p, 720/50p
Scan frequency Horizontal : 67.43 kHz, Vertical : 59.94 Hz
Horizontal : 56.25 kHz, Vertical : 50 Hz
Horizontal : 33.72 kHz, Vertical : 59.94 Hz
Horizontal : 28.13 kHz, Vertical : 50 Hz
Horizontal : 44.96 kHz, Vertical : 59.94 Hz
Horizontal : 37.50 kHz, Vertical : 50 Hz
Sync system Internal
Sensitivity F 4 standard (2000 lx, 3000K)
Minimum illumination
8 lx standard (50 IRE, F1.4, gain 㸩18 dB,
gamma setting ON (setting value 0), 3000 K)
Lens mount C mount
Operating temperature (32㼲 㼲 F) to 40 0 F to 104 䉔 䉔
Operating humidity Less than 90% (non condensing)
Weight Approx. 148 g (0.326 lbs)
External dimension 44(W) × 44(H) × 78(D) mm (1.73”(W) 㽙㻃1.73”(H) 㽙㻃3.07”(D) )
Scene file A, B, C, D, E
White balance
ATW䟺Automatic tracking white balance䟻, AWB䟺Automatic white balance䟻,
MANUAL䟺Manual䟻
Gain MANUAL (Manual), OFF (0 dB)
Output signal DVI (Digital RGB) DVI-D terminal
USB Video Class 1.1 mini-USB terminal (in conformity with USB 2.0)
Design and specifications are subject to change without notice.
9. SPECIFICATIONS
