23
䟺 䟺䟺 䟺 3䠀 䠀 䠀 䠀 3䟻䟻䟻䟻 Changing gain in MANUAL mode
White balance mode AWB, ATW, MANUAL
Red gain adjustment -100 to 100
-- 3 WHT BAL --
Blue gain adjustment -100 to 100
MODE
R GAIN
Color temperature setting 3200K, 5600K
B GAIN
C TEMP
MANUAL
0
0
3200K
(a) Changing the red gain
䐖 Move the “䊲” to R GAIN by pressing [MENU UP], [MENU DOWN] buttons.
䐗 Select the desired value of red gain by pressing [DATA UP], [DATA DOWN] buttons.
(b) Changing the blue gain
䐖 Move the “䊲” to B GAIN by pressing [MENU UP], [MENU DOWN] buttons.
䐗 Select the desired value of blue gain by pressing [DATA UP], [DATA DOWN] buttons.
Move up and down
by pressing
MENU UP,DOWN
Select the desired
value by pressing
DATA UP,DOWN
-100 0 100
[DATA UP] ࠉRed is increased.
Red is decreased. ࠉ [DATA DOWN]
-100 0 100
[DATA UP] ࠉBlue is increased.
Blue is decreased. ࠉ [DATA DOWN]
(c) Changing color temperature setting
䐖 Move the “䊲” to C.TEMP by pressing [MENU UP], [MENU DOWN] buttons.
䐗 Select either 3200K or 5600K by pressing [DATA UP], [DATA DOWN] buttons.
