26
䟺 䟺䟺 䟺 5䟻䟻䟻䟻 MATRIX(Matrix color correction)
Matrix color correction
ON, OFF
Red hue setting -- 5 MATRIX -- Yellow hue setting
Red gain setting MATRIX ON Yellow gain setting
Green hue setting R HUE 0 Ye HUE 0 Cyan hue setting
R GAIN 0 Ye GAIN 0
Green gain setting
G HUE 0 Cy HUE 0
Cyan gain setting
G GAIN 0 Cy GAIN 0
Blue hue setting B HUE 0 Mg HUE 0 Magenta hue setting
B GAIN 0 Mg GAIN 0
Blue gain setting Magenta gain setting
䟺 䟺䟺 䟺 5䠀 䠀 䠀 䠀 1䟻䟻䟻䟻 Changing Matrix color correction ON/OFF
䐖 Move the “䊲” to MATRIX by pressing [MENU UP], [MENU DOWN] buttons.
䐗 Select either ON or OFF by pressing [DATA UP], [DATA DOWN] buttons.
䟺 䟺䟺 䟺 5䠀 䠀 䠀 䠀 2䟻䟻䟻䟻 Changing MATRIX setting
䐖 Move the “䊲” to the desired item by pressing [MENU UP], [MENU DOWN] buttons.
䐗 Select the desired value of color by pressing [DATA UP], [DATA DOWN] buttons.
* When matrix color correction is set to OFF, the color cannot be adjusted.
Move up and down
by pressing
MENU UP,DOWN
Select the desired
value by pressing
DATA UP,DOWN
-15 0 15
[DATA UP]
[DATA DOWN]
