IRDET
O card reader:
Insert appropriate smart card carefully into the slot (gold chip at bottom, and in direction of insertion) until it meets resi- stance
On/standby mode
LNB input
SCAR
T connection TV set
SCAR
T connection VCR
Audio outputs
RS-232 connection/interface
HF output
Mains power
connection
Input terrestri-
al antenna
Programme selection
up/down
LED display
