Teletext filtering in accordance with standard ETS 300 472
Entry teletext data compliant to ITU-R BT.653-2; lines: 6-22 and 320-335
TV-SCART:
Output
CVBS with RGB, or only CVBS, or only S-VHS (switchable)
VCR-SCART::
Input
CVBS with RGB or S-VHS
Output CVBS or S-VHS
Serial Interface RS 232:
Type
RS 232 bi-directional
Bitrate Max. 115.2 Kbit/s
Connection 9-pin D-SUB connector, male
Function Pre-programming and updating operational software
PLL-Modulator:
Output range
UHF channels 21 to 69
Antenna input 47….862 MHz
Input/output impedance 75 Ohm
Antenna output 47…862 MHz, including re-modulated UHF signal
Video system PAL / SECAM
LNB power supply:
LNB power
Max. 400 mA, short circuit detected
LNB voltage vertical <14.0 V no load, >11.5 V at 400 mA
LNB voltage horizontal <20 V no load, >17.5 V at 400 mA
LNB switched off in Standby mode
22 kHz-Modulation: 22 kHz, amplitude 0.6 V +/- 0.2 V
Programme memory/ Satellite positions:
No. of programmes user list TV:
999 TV programmes (F1 to F999)
No. of programmes user list Radio: 999 radio programmes (r1 to r999)
Number of Programmesl:
Bouquet lists TV/Radio
total of 2000 programmes possible in bouquet lists
Number of active satellite positions:
Max. 4 (DiSEqC 1.0, SAT POSITION/ SAT OPTION)
Total number of satellite position: 32
One home transponder is stored in memory for each of the 32 satellite positions. This trans-
ponder facilitates automatic channel/programme search on each satellite position.
EPG Data:
EPG preview:
Maximum 7 days in advance
Memory capacity: Programmable for a maximum of 50 programmes
Timer:
Events
Maximum 128 events, one year in advance
Remote Control System: RC-5
Sub-system address 8 (SAT 1)
Modulation frequency 36 kHz
Infrared wavelength 950 nm
