Texas Instruments MSP430 User Manual
Page 59
LED connected
to P1.0
Connector J5
External power connector
Jumper JP1 to 'ext'
Jumper JP3
Open to disconnect LED
Jumper JP2
Open to measure current
www.ti.com
MSP-TS430QFN23x0
Figure B-18. MSP-TS430QFN23x0 Target Socket Module, PCB
59
SLAU278F – May 2009 – Revised December 2010
Hardware
© 2009–2010, Texas Instruments Incorporated
