7

When you turn the UPS ON, it will perform a brief self-test. See charts below for display sequences.

Display sequence when AC input power is present:

Display sequence when AC input power is absent:
(possible only with the "Battery Start" Switch)

SELF TESTING...

SELF TESTING...

RECTIFIER OK

BATTERY OK

CHARGER OK

DC TO DC OK

BATTERY OK

INVERTER TEST

DC TO DC OK

INVERTER TEST

4.3 Self-Testing

4. Operation (Normal Conditions)

(continued)

Momentarily press the “SELECT” button on the front panel to browse through different power readings on the LCD Display.

4.4 LCD Display Select Button

BYPASS OUTPUT
R: XXXV R: XXX.XV
S: XXXV S: XXX.XV
T: XXXV T: XXX.XV

(Bypass & Output Voltage)

OUTPUT

LOAD

R: XXX%

XXX.XA

S: XXX%

XXX.XA

T: XXX%

XXX.XA

(Output Load & Current)

MAINS

INVERTER

R: XXXV

R: XXX.XV

S: XXXV

S: XXX.XV

T: XXXV

T: XXX.XV

(Mains & Inverter Voltage)

BYPASS:

XX.X Hz

MAINS:

XX.X Hz

OUTPUT:

XX.X Hz

INVERTER: XX.X Hz

(Bypass, Mains, Output & Inverter Frequency)

(Charger Mode, Charger/Battery Voltage & Battery Percentage)

(Serial Number, DC BUS Voltage, Temperature & Firmware Version)

(Button Functions)

CHARGE FLOATING
CHARGER: XXX.XV
BATTERY: XXX.XV
BATTERY: XXX.X%

SN:

XXX

DC BUS:

XXV - XXV

TEMP:

XXX.X˚C

VERSION: XXX

ON:

UPS START

OFF:

UPS BYPASS

SEL:

UPS MESSAGE

ENT:

SET UPS

Press "SELECT" Button

Press "SELECT" Button

Press "SELECT" Button

Press "SELECT" Button

Press "SELECT" Button

Press "SELECT" Button

Press "SELECT" Button
