8
Rear Panel
The 3-pronged power plug and the power on/off switch are located at the
Rear Panel of the MIL-SM808G switch, as shown in Figure 2-3. The
switches will work with AC in the range 100-240V AC, 50-60Hz.
Power Plug
Power
On/Off
Switch
Figure 2-3. The Rear Panel of the MIL-SM808G Switch
Desktop Installation
Set the switch on a sufficiently large flat space with a power outlet nearby.
The surface where you put your switch should be clean, smooth, level,
and sturdy. Provide enough clearance around the switch to allow
attachment of cables, power cord and air circulation.
Attaching Rubber Feet
A. Make sure the mounting surface on the bottom of the Switch is grease
and dust free.
B. Remove adhesive backing from the rubber feet.
C. Apply the rubber feet to each corner on the bottom of the switch. These
footpads can prevent the Switch from shock/vibration.
