J2: CD_IN Connector (S5375AG2NR only)
4 1
Pin Signal Pin Signal
1 R 2 GND
3 GND 4 L
J4: Front Panel Audio Connector (S5375AG2NR only)
1 9
2 10
Pin Signal Pin Signal
1 MIC1_LN 2 GND
3 MIC1_RN 4 reserved
5 FRONT_RN
6 MIC_JD
7 SENSE 8 Key
9 FRONT_LN
10 LINE_JD
J10: Chassis Intrusion Connector
1
Use this header to connect with the front intruder button
which indicates the warning message when the system
cover is opened.
Pin Signal
1 Intruder
2 GND
J5: AUX_IN Connector (S5375AG2NR only)
1 4 Pin Signal Pin Signal
1 R 2 GND
3 GND 4 L
J6: IPMB Connector
1 Pin Signal Pin Signal
1 IPMB DATA 2 GND
3 IPMB CLK 4 NC
SATA0/1/2/3/4/5: Serial ATA Connector
7 GND
6 RXP
5 RXN
4 GND
3 TXN
2 TXP
7
1
1 GND
Connects to the Serial ATA ready drives via the
Serial ATA cable.
