SEM/SEMW Oven Care and Use Manual
39
Warming Drawer Parts and Removal
To remove the drawer:
WARNING:
Do not remove drawer
while hot. Be sure drawer is empty be-
fore removing.
• Pull drawer to fully open position.
• Lift up on left side Release Lever and press down
on the right side Release Lever.
• Firmly pull the drawer outward until each Drawer
Rail pulls free from each Inner Cabinet Slide.
Retract Cabinet Rails while drawer is being
cleaned.
To replace the drawer:
• Be sure Cabinet Rails are pushed inside cabinet.
• Align each Drawer Rail to each Inner Cabinet
Slide. Use the Slide Lock to guide placement.
• Close the drawer completely; the Slide Lock will
secure the drawer.
• Pull out drawer fully to check that both locks are
engaged.
Removing the Drawer
Parts
1. Moist/Dry Selector
2. Stainless Steel Drawer Inte-
rior
3. Gasket
4. Rail Lock
5. Thermostat Dial
6. ON Light Lens
7. ON Light Viewer
1
2
3
4
5
6
7
Warming Drawer Parts and Removal
Front View
of the Drawer
