5-4-4. Port Controls

1. This page can Change every port status

State: User can disable or enable port 1-8, port 9 always enable.
Auto Negotiation: Port 1-8 is fixed to disable mode, and port 9 is enabled.
Speed setting: The speed mode is fixed. 100Mbps (1-8 port) , 1000Mbps
(GBIC port)

Duplex setting: port 1-8 support Full or Half Duplex, port 9 only support
Full Duplex.

Flows control setting: Port 1-8 can enable/disable, port 9 always enable.

63
