ICC

5. In the dialog that appears, select Manually configure network settings.

6. Enter the desired IP Address, Subnet Mask, Default Gateway and case-

sensitive system password (default is “icc”) in the appropriate boxes, then
click Apply.

7. A popup dialog box will prompt you to reboot. Click Reboot Device.

Rebooting may require 30s or more to complete. When the device status
indicates “Ready”, click Close.

8. The discovery utility will automatically rescan the network. Confirm that the

new IP address has been accepted by the device.

7.2 Via the Drive’s Keypad

This section applies to G9 drives only.

This feature is not currently supported.

7.3 Via the Web Page

Once an initial IP address has been assigned to the device and the
configuration web page can be accessed, the IP address-related parameters
can also be modified via the web page. Refer to section 10.7.5.
