Chapter 1. The Quick Start Guide
Initial Network Configuration
Initially, the B050-000 network interface is configured with the parameters shown in
Table 1-1.
Table 1-1. Initial Network Configuration
Parameter Value
IP auto configuration DHCP
IP address -
Netmask 255.255.255.0
Gateway none
IP access control none
Warning
If the DHCP connection fails on boot up, the B050-000 will not have an
IP address.
If this initial configuration does not meet your local requirements, adjust the values
to your needs. You may either configure the B050-000 via serial interface, or use the
setup tool that can be found on the CD ROM delivered with this package.
B050-000 Setup Tool
The setup tool is used to determine the IP address assigned to the B050-000 by the
DHCP server or to change the device’s initial network configuration.
Main Window
Figure 1-4. B050-000 setup tool (Windows version)
4
