(E) 46/52/62HM94
Copyright © 2004 TOSHIBA CORPORATION. All rights reserved. 101
Chapter 11: Appendix
Video/Audio Terminals (continued)
HDMI ™ INPUT:
HDMI compliant (type A connector)
HDCP compliant
E-EDID** compliant
Suggested scan rates: 1080i, 480p, 480i, 720p
HDMI Audio: 2-channel PCM; 32/44.1/48 kHz sampling
frequency; 16/20/24 bits per sample
NOTE: This TV does not provide HDMI OUTPUT.
VIDEO/AUDIO OUTPUT (also for recording):
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent,
2.2 k ohm or less)
VARIABLE AUDIO OUTPUT:
0–300 mV(rms) (30% modulation equivalent,
2.2 k ohm or less)
G-LINK ™ and IR OUTPUT:
3 V(p-p), 3.5 mm mono socket (IR blaster cables supplied)
IEEE-1394 INPUT/OUTPUT:
IEEE-1394 compliant
DIGITAL AUDIO OUTPUT:
Optical type
Dimensions
46HM94: Width: 53-1/8 inches (1664 mm)
Height: 31-13/16 inches (808 mm)
Depth: 15-1/4 inches (387 mm)
52HM94: Width: 58-3/8 inches (1483 mm)
Height: 35-1/16 inches (891 mm)
Depth: 15-1/4 inches (387 mm)
62HM94: Width: 67-1/16 inches (1703 mm)
Height: 40-15/16 inches (1040 mm)
Depth: 18-3/16 inches (462 mm)
Weight
46HM94: 78 lbs (35.38 kg)
52HM94: 83 lbs (37.65 kg)
62HM94: 99 lbs (44.90 kg)
Supplied Accessories
• Two dual-wand IR blaster cables
• Remote control with two size “AA” alkaline batteries
Optional Stands:
46HM94: ST4694 or ST4684
52HM94: ST5294 or ST5284
62HM94: ST6294 or ST6284
_________
** E-EDID = Enhanced-Extended Display Identification
Specifications
NOTE:
• This model complies with the specifications listed below.
• Designs and specifications are subject to change without notice.
• This model may not be compatible with features and/or specifications that may be added in the future.
Television System
NTSC standard
ATSC standard (8VSB)
Digital Cable (64 QAM, 256 QAM; in-the-clear, unencrypted*)
*Encrypted channels can be viewed on this TV
using a CableCARD. See page 12 for details.
Channel Coverage
VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mid band (A-8 through A-1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 125)
Power Source
120 V AC, 60 Hz
Power Consumption
250 W (average)
45 W in standby mode (power cord plugged in and power OFF)
Audio Power
15 W + 15 W
Speaker Type
Main: Two 4-inch (10cm) round
Tweeter: Two 1-5/8-inch (4cm) round
Video/Audio Terminals
S-VIDEO INPUT:
Y : 1 V(p-p), 75 ohm, negative sync.
C : 0.286 V(p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT:
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent,
22 k ohm or greater)
ColorStream ® (component video) HD INPUT:
Y : 1V(p-p), 75 ohm
PR: 0.7 V(p-p), 75 ohm
PB : 0.7 V(p-p), 75 ohm
AUDIO: 150 mV(rms), 22 k ohm or greater
Suggested resolutions: 1080i, 480p, 480i, 720p
NOTE: This TV does not provide ColorStream HD OUTPUT.
