Specifications
Note:
This model complies with the specifications listed
below.
Designs and specifications are subject to change
without notice.
This model may not be compatible with features and/or
specifications that may be added in the future.
Television System
NTSC standard
ATSC standard (8VSB)
Digital Cable (64 QAM, 256 QAM; in-the-clear,
unencrypted)
Channel Coverage
VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mid band (A-8 through A-1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 135)
Power Source: 120 V AC, 60 Hz
Power Maximum Current : 1.55 A
Power Consumption : : 0.6 W in standby mode
Audio Power: 3 W + 3 W
Speaker Type: Two 2-3/8 × 1-3/8 inches (6 Ч 35.2 Ч 2.6 cm)
Video/Audio Terminals
S-VIDEO INPUT:
Y: 1 V(p-p), 75 ohm, negative sync.
C: 0.286 V(p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT:
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent, 22 k
ohm or greater)
ColorStream ® (component video) HD INPUT:
VIDEO:Y: 1V(p-p), 75 ohm
P
R
: 0.7 V(p-p), 75 ohm
P B : 0.7 V(p-p), 75 ohm
Suggested formats: 1080i, 720p, 480p, 480i
AUDIO: 150 mV(rms), 22 k ohm or greater
•
•
•
HDMI™ INPUT:
HDMI compliant (type A connector)
HDCP compliant
Audio Lip Sync supported
Suggested formats: See table on the next page.
HDMI Audio: 2-channel Linear-PCM; 32/44.1/48 kHz
sampling frequency; 16/20/24 bits per sample
DIGITAL AUDIO OUTPUT:
Optical type
PC INPUT:
15-Pin D-sub Analog RGB
Dimensions
Width: 1’9-1/8 inches (535.5 mm)
Height: 1’4-1/8 inches (409.8 mm)
Depth: 9 inches (227.1 mm)
Mass (Weight) : 14.1 lbs (6.4 kg)
Operating conditions
Temperature: 32ºF - 95ºF (0ºC - 35ºC)
Humidity: 20 - 80% (no moisture condensation)
Supplied Accessories
Remote control with two size “AAA” batteries
Owner’s manual (this book)
Cleaning cloth
•
•
•
