17
CN8 onboard HS-6038 is a 3-pin fan power output connector.
CN8: Fan Power In Connector
PIN Description
1 GND
2 +12V
3 FAN In 1 1 3
GN
D
+
12V
FA
N In 1
3.17 Keyboard/Mouse Connectors
The HS-6038 offers two possibilities for keyboard connection. The
connections are via KB1 for an external PS/2 type keyboard/mouse or
via CN3 for an internal 5-pin cable converter to an AT keyboard.
CN3: 5-pin Keyboard Connector
PIN Description
1 Keyboard Clock
2 Keyboard Data
3 N/C
4 GND
5 +5V
1 2 3 4 5
KB1: PS/2 6-pin Mini DIN Keyboard/Mouse Connector
PIN Description
1 Keyboard Data
2 Mouse Data
3 GND
4 +5V
5 Keyboard Clock
6 Mouse Clock
Keyboard
Data
Mouse
Data
GND
+5V
1
2
3
4
5
6
Keyboard
Clock
Mouse
Clock
3.18 System Front Panel Connectors
The HS-6038 has one LED at location D1 that indicates the power-on
status. This visual feature of the IDE LED may also be connected to an
external IDE LED via connector CN4.
CN4: IDE LED Connector
PIN Description
1 +5V
2 HDD ACTIVE#
1 2
