9
3.3 Jumper List
Jumper Definition Setting Page
JP2 Host Bus Clock Rate Select: 133MHz FSB Open 10
JP3 Clear CMOS: Normal Operation Short 1-2 15
JP4 LAN2 Enabled/Disabled Select: Enabled Short 1-2 14
JP5 WDT Active Type Setting: System Reset Short 2-3 20
JP6 Short 3-4 25
JP7
DiskOnChip Address Select: 0D000H~
0D1FFH
Short 1-2 25
JP8 / JP9 /
JP11 / JP12
COM 2 Use RS-232 or RS-422/485 Select:
RS-232
Short 2-3
12
3.4 Connector List
Connector Definition Page
ATX1 20-pin ATX Power In Connector 16
CD1 CD-ROM Analog Input Connector 19
CD2 Line In Connector 19
CN1 Keylock Connector 17
CN2 Speaker Connector 18
CN3 5-pin Keyboard Connector 17
CN4 HDD LED Connector 17
CN5 SMI Signal Input Connector 19
CN6 2-pin ATX Power On Switch 16
CN7 2-pin Reset Button Connector 17
CN8 Fan Power In Connector 16
CN9 I 2 C Bus Connector 10
CN10 5-pin ATX Power In Connector 16
CN11 COM 1 Connector (5x2 header) 12
CN12 RS-422/485 Connector (5x2 header) 12
CN13 COM 2 Connector (5x2 header) 12
CF1 CompactFlash TM Connector 21
DIM1/DIM2 168-pin DIMM Sockets 10
FDC1 Floppy Connector 12
IDE1/IDE2 Primary/Secondary IDE Connectors 11
IR1 IrDA Connector 14
JP1 System Sensing Connector 18
JP13 MIC In / Audio Out Connector 19
KB1 PS/2 6-pin Mini DIN KB/MS Connector 17
LAN1 Dual RJ-45 Connector 14
LPT1 Parallel Connector 13
