11
CN9: I 2 C Bus Connector
PIN Description
1 SMBDATA
2 SMBCLK
3 GND
1 2 3
3.8 IDE Drive Connector
IDE1/IDE2 are standard 40-pin connector daisy-chain driver
connectors serving the PCI E-IDE drive provisions onboard the
HS-6038. A maximum of four IDE drives can be connected to the
HS-6038 via IDE1/IDE2.
IDE1/IDE2: Primary/Secondary IDE Connectors
PIN Description PIN Description
1 RESET 2 GND
3 DATA 7 4 DATA 8
5 DATA 6 6 DATA 9
7 DATA 5 8 DATA 10
9 DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GND 20 N/C
21 PDREQ 22 GND
23 PDIOW# 24 GND
25 PDIOR# 26 GND
27 PIORDY 28 GND
29 RPDACK- 30 GND
31 IRQ14 32 N/C
33 RPDA1- 34 PATA66DET
35 RPDA0- 36 RPDA2-
37 RPCS1- 38 RPCS3-
39 HDD ACTIVE 40 GND
1
2 40
39
3 5 7 9 17 19 21 23 25 27 29 31 33 11 13 15 35 37
4 6 8 10 18 20 22 24 26 28 30 32 34 12 14 16 36 38
