Page 67: Phaseo, Regulated switch mode power supplies

67
References
0
Power supplies
0
Power supplies for d.c. control circuits
Phaseo
®
regulated switch mode power supplies
ABL 7CEM single-phase regulated switch mode power supplies
Mains
input voltage
47...63 Hz
Output
voltage
Nominal
power
Nominal
current
Auto-protect
reset
Conforming
to standard
EN 61000-3-2
Reference
Weight
V
c V
W
A
kg
a 100 to 240
single-phase
wide range
c 110 to 220 (1)
24
7
0.3
auto
–
ABL 7CEM24003
0.150
15
0.6
auto
–
ABL 7CEM24006
0.180
30
1.2
auto
–
ABL 7CEM24012
0.220
ABL 7RE single-phase regulated switch mode power supplies
Mains
input voltage
47...63 Hz
Output
voltage
Nominal
power
Nominal
current
Auto-protect
reset
Conforming
to standard
EN 61000-3-2
Reference
Weight
V
c V
W
A
kg
a 100 to 240
single-phase
wide range
24
48
2
auto
–
ABL 7RE2402
0.520
72
3
auto
no
ABL 7RE2403
0.520
120
5
auto
no
ABL 7RE2405
1.000
240
10
auto
no
ABL 7RE2410
2.200
ABL 7RP single-phase regulated switch mode power supplies
Mains
input voltage
47...63 Hz
Output
voltage
Nominal
power
Nominal
current
Auto-protect
reset
Conforming
to standard
EN 61000-3-2
Reference
Weight
V
c V
W
A
kg
a 100...240
single-phase
wide range
c 110...220 (1)
12
60
5
auto/man
yes
ABL 7RP1205
1.000
24
72
3
auto/man
yes
ABL 7RP2403
0.520
120
5
auto/man
yes
ABL 7RP2405
1.000
240
10
auto/man
yes
ABL 7RP2410
2.200
48
144
2.5
auto/man
yes
ABL 7RP4803
1.000
a 100 to 240
single-phase
wide range
24
480
20
auto/man
yes
ABL 7RPM24200
2.300
ABL 7REQ 2-phase regulated switch mode power supplies
Mains
input voltage
47...63 Hz
Output
voltage
Nominal
power
Nominal
current
Auto-protect
reset
Conforming
to standard
EN 61000-3-2
Reference
Weight
V
c V
W
A
kg
a 380 to 415
24
120
5
auto/man
no
ABL 7REQ24050
0.850
240
10
auto/man
no
ABL 7REQ24100
1.200
ABL 7U 3-phase regulated switch mode power supplies
Mains
input voltage
47...63 Hz
Output
voltage
Nominal
power
Nominal
current
Auto-protect
reset
Conforming
to standard
EN 61000-3-2
Reference
Weight
V
c V
W
A
kg
a 3x380 to 415 24
240
10
auto/man
no
ABL 7UEQ24100 1.200
480
20
auto/man
no
ABL 7UEQ24200
2.100
a 3x400 to 520 24
120
5
auto/man
yes
ABL 7UES24050
1.300
240
10
auto/man
yes
ABL 7UPS24100
1.300
480
20
auto/man
yes
ABL 7UPS24200
2.300
960
40
auto/man
yes
ABL 7UPS24400
4.500
(1) Compatible input voltage.
ABL 7CEM
1
08700-13-M
ABL 7RE2405
ABL 7RP2405
ABL 7RP4803
43367-15-M
ABL 7P
pppp
108387
ABL-7REQ
530894
ABL 7UPS
10838
7-25-M
Presentation :
pages page 58, page 59
Characteristics :
pages page 62 - page 65
Dimensions :
page page 68
Schemes :
page page 69
