47
Characteristics
(continued)
0
IP 67 modular I/O splitter boxes
for fieldbuses
0
Advantys™
Distributed I/O, FTM splitter boxes
Digital input/output splitter box characteristics
Splitter box type
Inputs
Inputs/outputs
Compact
FTM 1DE08Cpp
FTM 1DE16C12
FTM 1DD08Cpp
FTM 1DD16C12
Expandable
FTM 1DE08CppE
FTM 1DE16C12E
FTM 1DD08CppE
FTM 1DD16C12E
Number of inputs/outputs
8 I
16 I
8 I/O
16 I/O
Internal consumption of splitter box
mA
30 (M8)
50 (M12)
50
30 (M8)
50 (M12)
50
Operating voltage
c V
24
Splitter box max. supply current
A
4
Auxiliary supply max. current
A
–
4 (only
FTM 1DD16C12)
Bus and I/O undervoltage detection
V
< 18
Input characteristics
Number of inputs
8 I
16 I
0...8 I
0...16 I
Conformity to IEC 1131-2
Type 2
Compatibility with 2-wire/3-wire
proximity sensors
Yes
Input values
Nominal voltage
c V
24
Maximum current
mA
200
Sensor power supply
V
18...30
Logic
Positive
Input filtering
ms
1
Channel status indication
By LED (yellow), one LED per input
Protection against reversed polarity
Yes
Output characteristics
Number of outputs
–
0...8 O
0...16 O
Output type
–
Transistor
Nominal output values
Voltage
c V
–
24
Current
A
–
0.5
Response time
ms
–
< 0.5
Max. switching cycle
Hz
–
Resistive: 50
Inductive: 5
Max. lamp load
W
–
10
Channel status indication
–
By LED (yellow), one LED per output
Output connection/cable lengths
–
0.34 mm
2
/ 5 m (#22 AWG / 16.4 ft.) max
0.75 mm
2
/ 10 m (#19 AWG / 32.8 ft.) max
Analog input/output splitter box characteristics
Splitter box type
Inputs
Outputs
Compact
FTM 1AE04C12C
FTM 1AE04C12T
FTM 1AS04C12C
FTM 1AS04C12T
Number of inputs/outputs
4 I
4 I
4 O
4 O
Internal consumption of splitter box
mA
50
Operating voltage
c V
24
Maximum supply current
Splitter box
A
4
Per channel
A
≤ 0.2
≤ 1.6
Bus and I/O undervoltage detection
V
< 18
Input and output characteristics
Type
Differential 300
Ω
Differential 1 M
Ω
≤ 500 Ω
≥ 500 Ω
Current
Measuring range
0 to 20 mA, 4 to
20 mA
c ± 10 V, c 0 to
10 V
0 to 20 mA, 4 to
20 mA
c ± 10 V, c 0 to
10 V
Resolution
Bits
16
15 + Sign
12
11 + Sign
Conversion time
ms
≤ 2/channel
≤ 1/channel
Input filtering
ms
1
–
Channel status indication
By LED
Output connection/cable lengths
m (ft.)
30 (98.4) max.
Digital and analog splitter boxes diagnostic characteristics
Internal bus and I/O undervoltage detection
V
< 18
Internal bus communication
By LED
Channel and splitter box short-circuit
By LED
Cable breakage
By LED
Presentation, functions:
pages 36 - 41
Description:
page 43
Connections:
pages 44, 45
References:
pages 48, 49
Dimensions, schemes:
pages 50, 51
