Page 61: Continued), Phaseo, Regulated switch mode power supplies

61
Selection
(continued)
0
Power supplies
0
Power supplies for d.c. control circuits
Phaseo
®
regulated switch mode power supplies
Selection according to application characteristics
Type of mains supply
Single-phase
2-phase
3-phase
Rated mains supply voltage
a 100 to 240 V 50/60 Hz
c 110 to 220 V (1)
Wide range
100 to 240 V
50/60 Hz
Wide range
2 x 380 to 415 V
50/60 Hz
3 x 380 to 415 V
50/60 Hz
3 x 400 to 520 V
50/60 Hz
Wide range
Permissible variation
85 to 264 V, 47 to 63 Hz
c 100...250 V (1), c 105...370 V (2)
85 to 264 V
47 to 63 Hz
340 to 460 V
47 to 63 Hz
340 to 460 V
47 to 63 Hz
360 to 550 V
47 to 63 Hz
Output voltage
12 V
48 V
24 V
24 V
24 V
24 V
24 V
Output current
0.3 A
ABL
7CEM24003
0.6 A
ABL
7CEM24006
1.2 A
ABL
7CEM24012
2 A
ABL
7RE2402
2.5 A
ABL
7RP4803
3 A
ABL
ABL
7RP2403
7RE2403
5 A
ABL
ABL
ABL
ABL
ABL
7RP1205
7RP2405
7RE2405
7REQ24050
7UES24050
10 A
ABL
ABL
ABL
ABL
7RP2410
7RE2410
7REQ24100
7UEQ24100
20 A
ABL
7UEQ24200
40 A
Conforming to EN 61000-3-2
Yes (not applicable for ABL 7CEM)
No
No
No
No
Integrated automatic
protection
Yes
Automatic or manual restart on ABL 7RP
Automatic restart only on ABL 7CEM
Yes
Automatic restart
Yes
Automatic or manual restart
(1) Values for ABL 7RP power supplies, not indicated on the product.
(2) Values for ABL 7CEM power supplies, not indicated on the product.
Presentation :
pages 58, 59
Characteristics :
pages 62 - 65
References :
page 67
Dimensions :
page 68
Schemes :
page 69
