Power supplies for d.c. control circuits
Phaseo
®
modular regulated power supplies
Technical characteristics
Power supply type
ABL 7RM1202
ABL 7RM2401
ABL 7RM24025
Certifications
UL - CSA - TÜV
Conforming to standards
Safety
IEC/EN 60950-1 - IEC/EN 61131-2/A11
IEC/EN 60950-1
EMC
IEC/EN 61000-6-2 (IEC/EN 61000-6-1), IEC/EN 61000-6-3
Input circuit
LED indication
No
Input voltage
Nominal values
V
a 100 to 240
Permissible values
V
a 85 to 264
Permissible frequencies
Hz
47 to 63
Efficiency at nominal load
> 80%
> 84%
Current consumption
A
0.5 (100 V)/0.3 (240 V)
0.6 (100 V)/0.4 (240 V)
1.2 (120 V)/0.7 (240 V)
Current at switch-on
A
< 20
< 90 for 1 ms
Power factor
0.6
Output circuit
LED indication
Green LED
Nominal output voltage
V
c 12
c 24
Nominal output current
A
1.9
1.3
2.5
Precision
Output voltage
Adjustable
from 100 to 120%
Line and load regulation
± 4 %
± 3 %
Residual ripple - interference
mV
200
250
200
Micro-breaks
Holding time
for I max and Ue min
ms
> 10
Protection
Against short-circuits
Permanent/Thermal protection
Against overcurrent, cold state
< 1.7 In
< 1.6 In
< 1.4 In
Against overvoltage
V
< 10.5
< 19
Operating characteristics
Connections
Input
mm
2
AWG
1 x 2.5 (#14 AWG) or 2 x 1.5 (#16 AWG) screw terminals
Output
mm
2
AWG
1 x 2.5 (#14 AWG) or 2 x 1.5 (#16 AWG) screw terminals
Environment
Storage temperature
°C
(°F)
- 25 to + 70 (-13 to + 158)
- 40 to + 70 (-40 to + 158)
Operating temperature
°C
(°F)
- 20 to + 55 (-4 to + 131)
Maximum relative humidity
95 %
Degree of protection
IP 20
Vibration
IEC/EN 61131-2, IEC/EN 60068-2-6 test Fc
Operating position
Vertical
Connections
Series
No
Parallel
Yes (same references)
Dielectric strength
Input/output
3000 Vac/50 Hz/1 min
Protection class
conforming to VDE 0106 1
Class II without PE
Input fuse incorporated
Yes (not interchangeable)
Emissions
Conducted/radiated
IEC/EN 61000-6-3, EN 55011, EN 55022 CI:B
Immunity
Electrostatic discharge
IEC/EN 61000-6-2 (generic standard), IEC/EN 61000-4-2 (4 kV contact/8 kV air)
Electromagnetic
IEC/EN 61000-4-3 level 3 (10 V/m)
Conducted interference
IEC/EN 61000-4-4 level 3 (2 kV), IEC/EN 61000-4-6 (10 V)
Mains interference
IEC/EN 61000-4-11
Presentation:
page 54
References:
page 57
Dimensions:
page 57
Schemes:
page 57
