9600 Compressor Installation, Operation, and Maintenance
P/N 8040540
1-5
C
HELIX TECHNOLOGY CORPORATION
-
TI
CRYOGENICS
Weight
The weight of the Compressor is listed in Table 1-1.
Electrical
The electrical specifications of the Compressor are listed in
Table 1-2.
Table 1-1: Compressor Weight
Weight
200lbs./91kg
Table 1-2: Electrical Input Specifications
Parameter
Value
Operating Voltage Range
180 - 253 VAC
Line Frequency
50/60 Hz
Phase
3
Nominal Input Power
5.5 KW
Nominal Power Factor
0.85
Rated FL/LR* Current
16.2/80
Minimum Electrical Service
30 Amps
*FL/LR = Full Load/Locked Rotor
