Specifications
Dimensions
The dimensions of the Compressor are shown in Figure 1-2.
Figure 1-2: 9600 Compressor Dimensions
CAUTION
Do not place a weight greater than 75 lbs. (34Kg) on top of the
Compressor.
19.52 IN.
(496 MM)
21.50 IN.
(546 MM)
1.28
(32MM)
23.36 IN.
(593 MM)
3.18 IN.
(81 MM)
14.4 IN.
(366 MM)
