Finalizing the Installation
(for qualified installers only)
49
© Travis Industries 4090507 100-01217_000
Back Left Log
The pin on the center log inserts into the
hole on the back of the back left log.
This groove on the log fits over the grate.
When in place, the log looks like the picture
to the right.
