Specifications
AMPLIFIER SECTION
VIDEO SECTION
TUNER SECTION
FM
AM
GENERAL
REMOTE CONTROL
Specifications and features are subject to change without notice. Power sup-
ply and voltage vary depending on the area in which the unit is purchased.
Continuous Average Power output (FTC)
All channels:
100 watts per channel min. RMS at
8
Ω, 2 channels driven from 20 Hz
to 20 kHz with no more than 0.08%
total harmonic distortion.
Dynamic power output:
230 watts
×
2 at 3
Ω
170 watts
×
2 at 4
Ω
115 watts
×
2 at 8
Ω
Total Harmonic Distortion:
0.08% at rated power
0.08% at 1 watt output
IM Distortion:
0.08% at rated power
0.08% at 1 watt output
Damping Factor:
60 at 8
Ω
Input Sensitivity and Impedance
DIGITAL INPUT (OPTICAL 1, 2):
0.5 Vp-p, 75
Ω
DIGITAL INPUT (COAXIAL):
0.5 Vp-p, 75
Ω
LINE (CD, VIDEO 1, 2, 3, TAPE):
200 mV, 47 k
Ω
Multichannel Input
(DVD FRONT L/C/R, SURR L/R):
200 mV, 47 k
Ω
(SUBWOOFER):
36 mV, 47 k
Ω
Output Level and Impedance
Rec out (TAPE, VIDEO 1):
200 mV, 470
Ω
Pre out (SUBWOOFER):
1 V, 470
Ω
Frequency Response:
10 Hz to 100 kHz,
+1/–3 dB (Direct mode)
Tone Control
Bass:
±12 dB at 20 Hz
Treble:
±12 dB at 20 kHz
Signal-to-Noise Ratio:
CD/TAPE: 100 dB
(IHF-A, Direct mode)
Muting: –50
dB
Input Sensitivity and Impedance
VIDEO (DVD, VIDEO 1, 2, 3):
1 Vp-p, 75
Ω
S VIDEO (DVD, VIDEO 1, 2, 3):
1 Vp-p, 75
Ω (Y)
0.28 Vp-p, 75
Ω (C)
COMPONENT VIDEO 1, 2:
1 Vp-p, 75
Ω (Y)
0.7 Vp-p, 75
Ω (P
B
, P
R
)
Output Level and Impedance
VIDEO (VIDEO 1, 2, MONITOR):
1 Vp-p, 75
Ω
S VIDEO (VIDEO 1, 2, MONITOR):
1 Vp-p, 75
Ω (Y)
0.28 Vp-p, 75
Ω (C)
COMPONENT VIDEO OUT:
1 Vp-p, 75
Ω (Y)
0.7 Vp-p, 75
Ω (P
B
, P
R
)
Tuning Range:
87.50-108.00 MHz (100 kHz steps)
Usable Sensitivity
Mono:
11.2 dBf, 1.0 µV (75
Ω, IHF)
0.9 µV (75
Ω, DIN)
Stereo:
17.2 dBf, 2.0 µV (75
Ω, IHF)
23 µV (75
Ω DIN)
50 dB Quieting Sensitivity
Mono:
17.2 dBf, 2.0 µV (75
Ω)
Stereo:
37.2 dBf, 20.0 µV (75
Ω)
Capture Ratio:
2.0 dB
Image Rejection Ratio:
40 dB
IF Rejection Ratio:
90 dB
Signal-to-Noise Ratio
Mono: 76
dB
Stereo: 70
dB
Alternate Channel Attenuation:
55 dB
Selectivity: 50
dB
(DIN)
AM Suppression Ratio:
50 dB
Total Harmonic Distortion
Mono: 0.2%
Stereo: 0.3%
Frequency Response:
30 Hz-15 kHz, –1.0 dB
Stereo Separation:
45 dB at 1 kHz
30 dB at 100 Hz-10 kHz
Tuning Range:
530-1,710 kHz (10 kHz steps)
Usable Sensitivity:
30 µV
Image Rejection Ratio:
40 dB
IF Rejection Ratio:
40 dB
Signal-to-Noise Ratio:
40 dB
Total Harmonic Distortion:
0.7%
Power Supply and Power Consumption:
AC 120 V, 60 Hz
5.2 A
Dimensions (W
×
H
×
D):
17-1/8"
Ч
5-7/8"
Ч
14-13/16"
435
Ч
150
Ч
376 mm
Weight:
21.8 lbs., 9.9 kg
Transmitter: Infrared
Signal range:
Approx. 16 ft., 5 meters
Power supply:
Two “AA” batteries (1.5 V
Ч
2)
