Display – Onkyo AV RECEIVER TX-NR5009 User Manual
Page 9
9
En
For detailed information, see the pages in parentheses.
ON/STANDBY button (
Remote control sensor and transmitter (
)
)
MASTER VOLUME control and indicator (
HDMI THRU indicator (
)
PURE AUDIO button and indicator (
Input selector buttons and indicators (
)
Front flap
Gently push on the lower end of the front panel to
open the flap.
PHONES jack (
)
ZONE 2, ZONE 3, and OFF buttons (
)
TONE and Tone Level buttons (
)
MONITOR OUT button (
DISPLAY button (
)
TUNING, PRESET (
), arrow and enter
buttons
DIMMER button (North American models) (
MEMORY button (
TUNING MODE button (
LISTENING MODE buttons (
)
WHOLE HOUSE MODE button (
SETUP MIC jack (
)
SETUP button (
)
HOME button (
)
RETURN button
USB port (
AUX INPUT jacks (
,
POWER button (European and Asian models)
)
RT/PTY/TP button (European and Asian models)
(
)
For detailed information, see the pages in parentheses.
Speaker/channel indicators
Z2 (Zone 2) indicator (
A and B speaker indicators (
Z3 (Zone 3) indicator (
Listening mode and format indicators (
)
,
and cursor indicators (
NET indicator (
,
Tuning indicators
RDS indicator (excluding North American models)
(
)
AUTO indicator (
TUNED indicator (
)
FM STEREO indicator (
)
Audio input indicators
Bi AMP indicator (
)
Audyssey indicator (
)
Dynamic EQ indicator (
)
(Dolby) Vol indicator (
)
Dynamic Vol indicator (
)
Headphone indicator (
Message area
MUTING indicator (
Volume level (
)
USB indicator (
,
SLEEP indicator (
Display
