Onkyo AV RECEIVER TX-NR5009 User Manual
Page 66
66
En
HDMI
■
HDMI Control(RIHD)
`
Off
`
On
Turn this setting on to allow
-compatible
components connected via HDMI to be controlled by the
AV receiver (
Note
• When the setting is set to “On” and the menu is closed, the
names of connected
-compatible components and
“RIHD On” are displayed on the AV receiver.
“Search…”
→ “(name)” → “RIHD On”
When the AV receiver cannot receive the name of the
component, it is displayed as “Player
*
” or “Recorder
*
”, etc (“
*
”
shows up and indicates the number of components, when two or
more are received).
• When an
-compatible component is connected to the
AV receiver via an HDMI cable, the name of the connected
component is displayed on the AV receiver display. For
example, while you are watching TV broadcasting, if you
operate a Blu-ray Disc/DVD player (being powered on) with the
remote control of the AV receiver, the name of the Blu-ray
Disc/DVD player will be displayed on the AV receiver.
• Set it to
“
Off
”
when a connected piece of equipment is not
compatible or it is unclear whether the equipment is compatible
or not.
• If operation is not normal when set to
“
On
”
, change the setting
to
“
Off
”
.
• Refer to the connected component’s instruction manual for
details.
• When “HDMI Control(RIHD)” setting is set to “On”, the
power consumption on standby mode slightly increases.
(Depending on the TV status, the AV receiver will enter standby
mode as usual.)
• The
control does not support HDMI OUT SUB. Use
HDMI OUT MAIN instead.
• When the source equipment is connected with the
connection, it may malfunction if “HDMI Control(RIHD)” is
set to “On”.
■
HDMI Through
`
Off
`
Auto:
Detects the signal and automatically selects the input
source.
`
BD/DVD, VCR/DVR, CBL/SAT, GAME, PC,
AUX, TV/CD, PHONO, PORT:
Selects the input source for which the HDMI
Through function is enabled.
`
Last:
The HDMI Through function is activated on the
input source selected at the time of setting the AV
receiver to standby mode.
When enabling the HDMI Through function, regardless of
whether the AV receiver is on or in standby, both audio
and video streams from an HDMI input will be output to
the TV or other components via HDMI connection. The
HDMI THRU and HDMI indicators light when enabled
(HDMI is dimly-lit).
This setting is set to “Auto” automatically when the above
“HDMI Control(RIHD)” is set to “On”.
Note
• Only the input source assigned to the HDMI IN via “HDMI
Input” is enabled (
• The power consumption during standby mode will increase
during the HDMI Through function; however in the following
cases, the power consumption can be saved:
– The TV is in standby mode.
– You are watching a TV program.
• Refer to the connected component’s instruction manual for
details.
• Depending on the connected component, the correct input source
may not be selected with the setting set to “Auto”.
• This setting is set to “Off” automatically when the “HDMI
Control(RIHD)” setting is set to “Off”.
■
Audio TV Out
`
Off
`
On
This preference determines whether the incoming audio
signal is output from the HDMI output. You may want to
turn this preference on if your TV is connected to the
HDMI output and you want to listen to the audio from a
connected component through your TV’s speakers.
Normally, this should be set to “Off”.
Note
• If “On” is selected and the audio can be output from the TV, the
AV receiver will output no sound through its speakers. In this
case, “TV Speaker” appears on the display by pressing
DISPLAY.
• When
“
HDMI Control(RIHD)
”
is set to
“
On
”
, this setting is
fixed to
“
Auto
”
.
• With some TVs and input signals, no sound may be output even
when this setting is set to
“
On
”
.
• When “Audio TV Out” or
“
HDMI Control(RIHD)” is set to
“
On
”
and you’re listening through your TV’s speakers
(
), turning up the AV receiver’s volume control will
make the sound be output from the AV receiver’s front left and
right speakers. To stop the AV receiver’s speakers producing
sound, change the settings, change your TV’s settings, or turn
down the AV receiver’s volume.
• Listening mode cannot be changed when this setting is set to
“On” and the input source is not HDMI.
• If the “Monitor Out” setting is set to “Both(Main)” or
“Both(Sub)” (
) and if your TV connected to a
priority output cannot output the audio, the sound will be heard
from AV receiver’s speakers.
