Onkyo AV RECEIVER TX-NR5009 User Manual
Page 34
34
En
3
When you’ve finished making the settings, press
ENTER.
Perform the “Speaker Setup” according to your
speaker configuration:
– Speakers Type(Front A) (
)
– Speakers Type(Front B) (
)
– Powered Zone 2 (
)
– Powered Zone 3 (
)
– Front High + Front Wide (
– Subwoofer (
)
If you are using a subwoofer(s), select “1ch” or “2ch”
in the “Subwoofer” setting (
). If not,
select “No” and skip step 4.
When an optional unit is connected to the
UNIVERSAL PORT jack on the AV receiver, the
optional unit setting may appear on the speaker
setting menu.
4
Adjust the subwoofer volume level to 75 dB, and
then press
ENTER.
Test tones are played through the subwoofer. Use the
volume control on the subwoofer.
When the “Subwoofer” setting is set to “1ch” only,
the left-hand subwoofer (SW1) will be measured.
When the “Subwoofer” setting is set to “1ch” with
two subwoofers connected, the right-hand subwoofer
(SW2) will not be measured and no sound will be
output.
An error will occur if you set “Subwoofer” to “2ch”
without connecting any subwoofers, or with only one
subwoofer connected.
Note
• If your subwoofer does not have a volume control,
disregard the displayed level and press ENTER to proceed
to the next step.
• If you set the subwoofer’s volume control to its maximum
and the level displayed is lower than 75 dB, leave the
subwoofer’s volume control at its maximum and press
ENTER to proceed to the next step.
• If you use two subwoofers, perform this step twice.
5
Use / to select “Audyssey Quick Start” or
“Audyssey MultEQ XT32 Full Calibration”.
MultEQ XT32: Auto Setup
AUDYSSEY
Speakers Type(Front A)
Normal
Speakers Type(Front B)
No
Powered Zone 2
No
Powered Zone 3
No
6
Press
ENTER.
Audyssey MultEQ
®
XT32 Room Correction and
Speaker Setup starts.
Test tones are played through each speaker as
Audyssey MultEQ XT32 Room Correction and
Speaker Setup runs. This process takes a few
minutes. Please refrain from talking during
measurements and do not stand between speakers
and the microphone.
Do not disconnect the speaker setup microphone
during Audyssey MultEQ XT32 Room Correction
and Speaker Setup, unless you want to cancel the
setup.
If you select “Audyssey Quick Start”, you will go to
step 9.
7
Place the speaker setup microphone at the next
position, and then press
ENTER.
Audyssey MultEQ XT32 performs more
measurements. This takes a few minutes.
8
When prompted, repeat step 7.
9
Use / to select an option, and then press
ENTER.
The options are:
`
Save:
Save the calculated settings and exit
Audyssey MultEQ XT32 Room Correction and
Speaker Setup.
`
Cancel:
Cancel Audyssey MultEQ XT32 Room
Correction and Speaker Setup.
Tip
• You can view the calculated settings for the speaker
configuration, speaker distances, and speaker levels by
using
/
.
10
Use / to select a target, and use
/
to change
the setting.
After the results of Audyssey MultEQ XT32 have
been saved, the menu will display the “Audyssey”
(
),
Note
• When “Audyssey Quick Start” has been used for
measurement, “Audyssey” cannot be selected.
• These settings are applied to all input selectors.
11
Press
ENTER.
12
Disconnect the speaker setup microphone.
Save
Cancel
AUDYSSEY
MultEQ XT32: Auto Setup
Subwoofer
2ch
Front
40Hz
Center
40Hz
Surround
100Hz
Front Wide
None
Front High
100Hz
Surround Back
120Hz
Surround Back Ch
2ch
-- Review Speaker Configuration --
