You can set which speakers you want to use by priority. You can temporarily mute the output of the AV receiver.
Selecting Speaker Layout
1 Press RECEIVER followed by SP LAYOUT
repeatedly to select:
■
9.2 ch playback
`
Speaker Layout:SB/FH:
The sounds from surround back and front high
speakers are output by priority.
`
Speaker Layout:SB/FW:
The sounds from surround back and front wide
speakers are output by priority.
■
7.2 ch playback
`
Speaker Layout:FH:
The sound from front high speakers is output by
priority.
`
Speaker Layout:FW:
The sound from front wide speakers is output
by priority.
Note
• This setting cannot be selected when bi-amping the front
speakers (
➔ page 51
) or using Speakers B (
➔ page 51
)
or Powered Zone 2 ( ➔ page 51 ).
• Playback conditions may be limited depending on the
settings in “Speaker Settings” ( ➔ page 51 ) and
“Speaker Configuration” (
➔ page 52
).
• When a listening mode which doesn’t support front high,
front wide or surround back speakers is used, this setting
cannot be selected.
■
Speakers A or Speakers B Configuration
When “Speakers Type(Front B)” setting is set to
other than “No”, the relevant speaker indicator
lights (A or B), and you can choose a speaker
layout between Speakers A and Speakers B.
Speakers A or B can be switched regardless of
listening modes.
Note
• When using Speakers B, you cannot use front wide
speakers.
• While using Speakers B, you cannot use
Audyssey MultEQ ® XT32 Room Correction and Speaker
Setup, as well as Audyssey Dynamic EQ ® and
Audyssey Dynamic Volume ® .
Note that these layouts can only be selected
when “Front High + Front Wide” is set to “No”
(
➔ page 51
) and all speakers are enabled.
Note that these layouts can only be selected
when “Front High + Front Wide” is set to “No”
(
➔ page 51
) and front high and front wide
speakers are enabled (
➔ page 52
).
Muting the AV Receiver
1 Press RECEIVER followed by MUTING.
The output is muted and the MUTING indicator
flashes on the display.
Tip
• To unmute, press MUTING again or adjust the volume.
• Muting is automatically cancelled when the AV receiver is
set to standby.
Using Headphones
1 Connect a pair of stereo headphones with a
standard plug (1/4 inch or 6.3 mm) to the
PHONES jack.
While the headphones plug is inserted in the
PHONES jack,
indicator, speaker/channel
indicator FL and FR lights. (The Powered Zone 2/3
speakers are not turned off.)
Note
• Always turn down the volume before connecting your
headphones.
• When you connect a pair of headphones, the listening mode
is set to Stereo, unless it’s already set to Stereo, Mono,
Direct, or Pure Audio.
• If you connect an iPod or iPhone to the USB port on the
AV receiver, no sound will be output from the headphones
jack.
