Omron CPU Unit CJ2 - Manual (Page 37)

37
CompoNet Master Unit ■
Unit
classification
Product
name
Specifications
No. of
unit
numbers
allocated
Current
consumption (A)
Model Standards
Communications
functions
No. of I/O points per
Master Unit
5 V 24 V
CJ Special
I/O Units
CompoNet
Master Unit
• Remote I/O
communications
• Message communications
Word Slaves: 2,048 max.
(1.024 inputs and 1,024 outputs)
Bit Slaves: 512 max. (256 inputs
and 256 outputs)
1, 2, 4, or 8 0.4 — CJ1W-CRM21
U1, CE, UC1
certification
pending
CompoBus/S Master Unit ■
Unit
classification
Product
name
Specifications No. of
unit
numbers
allocated
Current
consumption (A)
Model Standards
Communications
functions
No. of I/O
points
Max. Units
mountable
per CPU Unit
5 V 24 V
CJ Special
I/O Units
CompoBus/S
Master Unit
Remote I/O
communications
256 max.
(128 inputs and
128 outputs)
40
1 or 2
(variable)
0.15 — CJ1W-SRM21
UC1, N, L,
CE
128 max.
(64 inputs and 64
outputs)
ID Sensor Units ■
Unit
classification
Product
name
Specifications
No. of
unit
numbers
allocated
Current
consumption (A)
Model Standards
Connected
ID Systems
No. of connected
R/W heads
External
power supply
5 V 24 V
CJ CPU
Bus Units
ID Sensor
Units
V680 Series
RFID System 1
Not required.
1
0.26
(See
note.)
0.13
(See
note.)
CJ1W-V680C11
UC, CE
certification
pending
2 2 0.32 0.26 CJ1W-V680C12
V600 Series
RFID System 1
Not required.
1 0.26 0.12 CJ1W-V600C11
UC, CE
2 2 0.32 0.24 CJ1W-V600C12
Note: To use a V680-H01 Antenna, refer to the V680 Series RFID System Catalog (Cat. No. Q151).
SYSMAC SPU (High-speed Data Storage Unit) ■
Unit
classification
Product name
Specifications
No. of
unit
numbers
allocated
Current
consumption
(A) Model Standards
PC Card slot
EtherNet (LAN)
port
5 V 24 V
CJ CPU
Bus Units
SYSMAC SPU Ver. 2
(High-speed Data
Storage Unit)
CF Card Type I/II × 1 slot
Use an OMRON
HMC-EF
Memory Card.
1 port (10/100Base-TX) 1 0.56 — CJ1W-SPU01-V2 UC1, CE
SPUConsole
Ver. 2.0 Functions: Unit settings, sampling settings, etc., for High-speed Data Collection Units
(required for making settings for this Unit)
OS: Windows 2000 or XP
WS02-SPTC1-V2
— Ver. 2.0 SYSMAC
SPU Data
Management
Middleware Ver. 2.0 Function: Data files collected by SYSMAC SPU Data Management
Middleware are automatically acquired at the personal
computer, and can be registered in a database.
OS: Windows 2000 or XP
1 license WS02-EDMC1-V2
5 licenses WS02-EDMC1-V2L05
Memory Cards Flash memory, 128 MB Note: Memory
Card is required
for data
collection. HMC-EF183
N, L, CE Flash memory, 256 MB (SYSMAC SPU only) HMC-EF283
Flash memory, 512 MB (SYSMAC SPU only) HMC-EF583
Ordering Information
